Sinotextile offers an economic and easy solution for advanced materils weaving, including carbon fiber, aramid fiber, glass fiber, UHMWPE and quartz fibre, basalt fiber and etc; covering the range of plain, twill, satin, unidirectional and spread tow fabrics.
Carbon fiber has been widely applied in industrial, firefighting, architecture, astronavigation fields due to it's high intensity, low density and small thickness. The carbon fiber fabric woven by our carbon fiber weaving machine has a smooth surface, the carbon fiber are well-arrayed. During weaving process weft and warp are precisely controlled by microcomputer, creating an even tension so that the strength of each pick carbon fiber are guaranteed. Our carbon fiber weaving loom is favored by clients from domestic and overseas due to its reliable quality and cost performance. Here is the features of Sinotextile carbon fiber weaving machine--
Adopt rigid rapier and positive weft insertion make it possible to weave high-quality advanced fiber reinforced fabrics.
Special parts and materials are used on the passages and channel for fibers to minimize fiber damage, like steel heddles.
No trimmed selvedge to reduce the waste of weft yarn and lower down the production cost.
Even tension controll by tension bracket and bobbin rack with fixed single warp yarn channel.
Winding of carbon fabric is realized by a pneumatic expanding shaft and paper tube, to make sure even arraying and easy doffing.
Unwinding creels ensure all the warp withstands a same and minimum tension, to realize continuous and safe production
Optional configuration like warp stop motion by infrared sensor, knot-free tying device can be offered.
Suitable for fabric width | 1000mm-1700mm, more options available according to requirement | |||||||||
| Suitable weaving patterns | plain, twill, satin, unidirectional | |||||||||
| Suitable fiber | carbon fiber, kevlar, fiberglass, UHMWPE, quartz fiber, basalt fiber and etc | |||||||||
| Weft density | 2-12picks/cm | |||||||||
| Areal density | 100-800gsm | |||||||||
| Thickness | 0.16-0.32mm | |||||||||
| Weft insertion | 1-4 colors | |||||||||
| Suggested weaving speed | 120-180rpm | |||||||||
| Driving motor | 6.5KW | |||||||||
| Electronic panel protection degree | IP65, dustproof, explosionproof panel box | |||||||||
| Optional configuration | off-loom takeup/winding, false beam let-off, infrared ray warp stop motion | |||||||||
